Step 4. Connect the "S" wire to the fuel-sender signal wire you removed from the stock fuel gauge. This wire is fed directly to the post on the fuel-level sender in the fuel tank. Twist these two wires together and cover them with a layer of electrical tape. Use your test lamp to determine the fuse for the dashboard instrument lights.
2 1 16 Wideband Pro Air Fuel Ratio 6 1 20 1 Afr Sport Comp
16" WIDE BAND AIR/fUEL RATIO mONITOR ® 2650-1143-00 Rev. A Installation 1. Disconnect the negative (-) battery cable. 2. Gauge can be mounted in a 21⁄ 16" dia. hole with brackets supplied. Gauge can also be mounted in Auto Meter Mounting Cup, or in Auto Meter Gauge Works Pods. 3. Wire gauge as shown. 12V Ignition Switch Good Engine Ground
